SiRON Y910-24 Series Wafer Type Solid State Relay

Name: SiRON Y910-24 Series Wafer Type Solid State Relay
Brand: SiRON
Rating: 5.0 (59 reviews)

Features

Medium voltage up to 4000VAc,insulation resistance 1000M0, DiN35 standard rail installation.
single contact load capacity 6A 250VAC/60VDC.
1 Normally open contact structure.
With short splices, common positive or common negative wiring can be simply performed.
Relay with socket,quick replacement,easy maintenance.

Quantity:
Availability:





Inquire Add to Basket PDF Export

Product Description

Relay specification parameter

Model		Y910-24-1-R	Y910-24-2-R	Y910-24-3-R
Control mode		Dc control DC	Dc controls AC	Dc control DC
Rated current		2A	2A	6A
Input voltage		12~32V
Instantaneous voltage		220VDC/900VAC
On-state step-down		<1.2DC/<1.6VAC
On-offtime		≤1mS/≤1ms
Off-state leakage		≤3mA/≤1mA
Insulation resistance		1000m Q以上
Dielectric withstand voltage		Between the coil and the contact, AC4000V 50/60Hz for 1 minute1min
		Between the same-level contacts, AC750V50/60Hz for 1 minute
Flammability categories under UI94		V-0
Dimensions		28515(mm)
Installation mode		PCB printed circuit board welding type
Suitable base		Y901-1-R/Y901-2-R
Contact parameters	Contact form	1NO
	Control voitage	3V-28VDC/15V-32VDC
	Control current	6-15mA
	On-oltage	1.5DC
	Turn-of voltage	1VDC
	Reverse voltage	32VDC
	Load voltage	5V-60VDC/24V-280VAC
	Load current	2A/6A
	Electrical durability	For over 100,000 cycles, AC250V,5A
		More than 200,000 times DC30V,3A
