SiRON K025 Series Proximity Switch Sensor Automatic Recognition Output Type

Name: SiRON K025 Series Proximity Switch Sensor Automatic Recognition Output Type
Brand: SiRON
Rating: 5.0 (96 reviews)

Features:

*Automatically identify and output NPN and PNP;
* Precise temperature compensation, with multiple protections;
* There is a third-class function with short-circuit fault alarm.

Quantity:
Availability:





Inquire Add to Basket PDF Export

Model:
K025 Series
Brand:
SiRON
Code:
9031809090

Proximity Sensor Automatic recognition output type multiple protections third-class function with short-circuit fault alarm Temperature compensation Alarm flash Lamp function Short -circuit Protection

Product Description

About selection

Selection example: K025-3 indicates the K025 series, serial number 3, with NPN/PNP automatic recognition,

normally open state.

Specifications

Name	Proximity switch-automatic identification output type
Model	K025-3		K025-4
Appearance
Size	M8		M12
Installation method	Embedded
Detection distance	1.5mm±10%		2.5mm±10%
Switch type	NPN / PNP Automatic recognition output type	Cable		Φ 3.9 3 C Grey P V C
Standard detection object	12×12×1mm	Switching frequency		500Hz
Set distance	0～1.5mm	Repeatability		<5%
Use voltage	5～30V DC	Operatingtemperature range		-20～+70℃
Switch working current	Max.100mA	Protection level		IP67
Residual pressure drop	≤1.1V@100mA	Shell material		Nickel plated brass
Shallow leakage current	≤100uA	Sensing surface material		PBT
Action indicator	NPN red light ； PNP green light	Cable length		2M
