SiRON P096 Series 480W DIN-rail with PFC Switching Power Supply

Name: SiRON P096 Series 480W DIN-rail with PFC Switching Power Supply
Brand: SiRON
Rating: 5.0 (10 reviews)

Features

AC and DC dual use (input voltage of the same terminal), output short circuit, over current, overvoltage,over temperature protection;
4000VAC high isolation voltage,low ripple noise;
Small size (32mm thickness): suitable for small chassis and narrow space installation;Installed on Ts-35/7.5/15;

Product Description

Order

Model		Voltage
P096		24V

Selection reference

Product Attributes

Model		P096
@230VAC) Electric shock		Cold start, 40A
Overcurrent Protection	range	1 1 0 %lo - 1 5 0 %lo
	type	Normal operation: After 1 second, output is interrupted and then resumes automatically
Short circuit protection		Fault mode, constant current mode operation for 1 second, with long-term short-circuit protection and self-recovery.
Isolation withstand voltage		Input - Output: 3 kVA C, Input P.E.: 2 kVA C, Output P.E.: 0.5 kVA C,(Test duration: 1 minute, leakage current < 10 mA)
Operating temperature		-30℃to+70℃
performance	EMI	CIS P R 3 2 / E N 5 5 0 32 Cla s s B; I E C / E N 6 1 0 0 0 - 3 -2 Cla s s A IEC/EN61000-3-2 ClassA and ClassD
	EMS	IEC/EN61000-4-2 Contact ± 6KV,IE C / E N 6 1 0 0 0 - 4 -3 10 V / m , IEC/EN61000-4-6 10Vr.m.s,IEC/EN61000-4-4,5,11
Safety standard		UL/EN/IEC/BS EN62368-1, UL61010-1, UL61010-2-201 & EN61558-1, EN62477
Shell material		IEC/EN/UL62368、UL61010、UL508
Wiring diameter		2 8 - 1 0AW G
Connector torque		M ax 0 . 4 N . m
Rail type		TS 35, the guide rail needs to be grounded
4 8 × 1 2 5 × 1 3 1 . 5
