SiRON P095-3 Series 240W Three-phase Metal Guide Switching Power Supply

Name: SiRON P095-3 Series 240W Three-phase Metal Guide Switching Power Supply
Brand: SiRON
Rating: 5.0 (60 reviews)

Features

AC and DC dual use (input voltage of the same terminal), output short circuit, over current, overvoltage,over temperature protection;
4000VAC high isolation voltage,low ripple noise;
Small size (32mm thickness): suitable for small chassis and narrow space installation;Installed on Ts-35/7.5/15;

Quantity:
Availability:





Inquire Add to Basket PDF Export

Product Description

Order

Model		Serial number	Voltage
P095		3	24V

Selection reference

Product Attributes

Model		P095-3
@230VAC) Electric shock		Cold start, 50A
Overcurrent Protection	range	≥130%lo
	type	Constant current protection, self-recovery
Short circuit protection		Constant current mode: After 3 seconds of constant current operation (typ), it can enter the hiccup mode and self-recover
Isolation withstand voltage		Input-output: 4kVAC, input-PE: 2.5kVAC Output -PE: 0.5kVAC, output -DC OK: 0.5kVAC
Operating temperature		-30℃to+70℃
performance	EMI	CISPR32 EN55032 Class B；IEC/EN6100-3-2 Class A；IEC/EN6100-3-3
	EMS	IEC/EN61000-4-2 Contact ±8KV,IEC/EN61000-4-3 10V/m, IEC/EN61000-4-4±2KV,IEC/EN61000-4-6 10Vr.m.s, IEC/EN61000-4-8 30A/m, IEC/EN61000-4-5/11
Safety standard		UL/EN/IEC/BS EN62368-1, UL61010-1, UL61010-2-201 & EN61558-1, EN62477
124×54×110
