SiRON P090 Series 75W Rail Type Switching Power Supply

Name: SiRON P090 Series 75W Rail Type Switching Power Supply
Brand: SiRON
Rating: 5.0 (10 reviews)

Features

AC and DC dual use (input voltage of the same terminal), output short circuit, over current, overvoltage,over temperature protection;
4000VAC high isolation voltage,low ripple noise;
Small size (32mm thickness): suitable for small chassis and narrow space installation;Installed on Ts-35/7.5/15;

Quantity:
Availability:





Inquire Add to Basket PDF Export

Product Description

Order

Model		Voltage
P090		24V

Selection reference

Product Attributes

Model		P083
@230VAC) Electric shock		Cold start, 45A
Overcurrent Protection	range	1 0 5 %lo - 1 5 0 %lo
	type	Constant current mode, self-recovery is possible after abnormal load conditions are removed.
Short circuit protection		Hiccup type, sustainable short circuit, self-healing
Isolation withstand voltage		Input-output: 4kVAC,Input PE: 2 kVA C, Output PE: 0.5 kVA C(Test for 1 minute, leakage current <10mA)
Operating temperature		-30℃to+70℃
performance	EMI	CISPR32 / EN55032 Class B ;IEC / EN61000 - 3 -2 Class A ;
	EMS	EC/EN 61000-4-2,Contac±4kv IEC/EN61000-4-310V/m, IEC/EN61000-4-610 Vr.m.s,IEC/EN61000-4-4,5,11
Safety standard		UL61010、EN62368
Shell material		Metal A L 1 1 0 0 , S GCC
Wiring diameter		26-10AWG
Connector torque		Max 0.4N.m
Rail type		TS35,The guide rail needs to be grounded.
3 2 × 1 2 5 × 8 7 . 5
