P081
SiRON
8504401400
Order
| Model | Voltage |
| P081 | 24V |
Product Attributes
| Model | Input voltage range | Power | Output voltage/current | Efficiency |
| P081-5V | 15W | 5V/3A | 82% | |
| P081-12V | 85-264VAC/ | 24W | 12V/2A | 88% |
| P081-15V | 120-370VDC | 30W | 15V/2A | 89% |
| P081-24V | 36W | 24V/1.5A | 89% | |
| P081-48V | 36W | 48V/0.75A | 90% |
| Model | P081 | |
| @230VAC) Electric shock | 45A | |
| Overcurrent Protection | range | ≥120%lo |
| range | self-recovery | |
| Short circuit protection | Hiccup type, sustainable short circuit, self-healing | |
| Isolation withstand voltage | Input-output: 4kVAC(Test for 1 minute, leakage current <10mA) | |
| Operating temperature | -40℃to+70℃ | |
| performance | EMI | CISPR32/EN55032 Class B |
| EMS | EC/EN 61000-4-2,Contac±4kv IEC/EN61000-4-310V/m, IEC/EN61000-4-610 Vr.m.s,IEC/EN61000-4-4,5,11 | |
| Safety standard | UL62368-1,IEC62368-1，EN62368-1 | |
| Shell material | Input-output: 4kVAC(Test for 1 minute, leakage current <10mA) | |
| Wiring diameter | 24-12AWG | |
| Connector torque | Max 0.4N.m | |
| Rail type | TS35 | |
| 35×92.66×58 | ||
