SiRON M403 Series Flange Right Angle Reducer

Name: SiRON M403 Series Flange Right Angle Reducer
Brand: SiRON
Rating: 5.0 (50 reviews)

Feature

* Use spiral bevel gears to achieve 90° turning, saving installation space;

* The reduction ratio is 4～100, the selection is more convenient;
* Full needle design, greatly improving rigidity and transmission torque;
* The main bearing adopts large-diameter thin-walled bearings to achieve high load capacity, and the 110 adopts tapered needle roller bearings;

* No need to replace the grease during the life of the product;

Quantity:
Availability:





Inquire Add to Basket PDF Export

Model:
M403
Brand:
SiRON
Code:
8501510090

5arc-min Right Angle Reducer 8arc-min Right Angle Reducer 10arc-min Right Angle Reducer

Product Description

About selection

Selection example: M403-064-4-F5-19HB16 indicates the M403 series, with a flange size of 64, a single-section ratio of 4, flange output, a backlash of 5 arc minutes, and a shaft sleeve nu mber of 19HB16.

Note: When placing an order, please provide the motor drawing of the matching reducer.

Specification

Size	Nominal input speed	Maximum input speed	Maximum radial load	Maximum axial load	Backlash
64	3000	6000	1500	750	single stage≤5/8 double stage:≤8/10
90	3000	6000	3300	1700
110	3000	6000	8500	4300
