SiRON H442 Series Single Door Floor Cabinet

Name: SiRON H442 Series Single Door Floor Cabinet
Brand: SiRON
Rating: 5.0 (69 reviews)

Features

25mm from the door to the ground;
2.5mm mounting plate, 22mm wide U-shaped flanges on both sides make the mounting plate stronger and easier to handle;
The movable cable lead-in cover plate at the bottom of the box can be replaced with each other, it is convenient to move, easy to lead the cable, and easy to open the hole to enter the wire;
Load-bearing hinge, easy to install, easy to change the door, the cabinet door can be opened 130°;
The back panel is detachable, fixed with screws, and can also be replaced with the cabinet door, polyurethane foam sealing tape;
The door can be opened on the left or right, and the standard modularized mounting hole design is convenient for use and installation;

Quantity:
Availability:





Inquire Add to Basket PDF Export

Product Description

Order

ad66b539500b632205a11e06fc91111f

Product standard configuration

One galvanized installation plate (including installation accessories) ② Install the depth guide rail ③ Front door opening and rear back panel ④ Simple packaging ⑤ One door installation strip (optional) ⑥ File Folder (optional) ⑦ Four lifting rings ⑧ Lock M821(Other models available) ⑨ Two-section cable introduction cover plate	● Color: RAL7032, RAL7035 ● Materials: Cold-rolled steel plate, galvanized installation plate ● Thickness: The door thickness is 2.0mm The thickness of the box is 1.5mm The mounting plate is 2.5mm ● Surface treatment: Phosphating, powder coating, wavy finish ● Protection grade: IP55 ● Technical details: You can consult the sales staff

Size specification
