K680~K682 Series
SiRON
9031809090
Selection reference
  | K680 series |
| The 5mm 5-megapixel lens C interface supports a maximum of 2/3-inch 5-megapixel CCD | |
 | K681 series |
| The 110mm 5-megapixel lens C interface supports a maximum of 2/3-inch 5-megapixel CCD | |
 | K682 series |
| The 150mm 5-megapixel lens with a C interface supports a maximum 2/3-inch 5-megapixel CCD |
Specification parameters
| Model | K680-65-0.3T50 |
| Object distance | 65 |
| Gain | 0.3x |
| Depth of field | 3.3 |
| Camera interface | C interface |
| Telecentric degree | ＜0.1 |
| Optical distortion | ＜0.1 |
| F.NO | Adjustable |
| MTF＞0.3(LP/MM) | 0.01 |
| Model | K681-110-0.3T50 |
| Object distance | 110 |
| Gain | 0.3x |
| Depth of field | 3.5 |
| Camera interface | C interface |
| Telecentric degree | ＜0.1 |
| Optical distortion | ＜0.1 |
| F.NO | Adjustable |
| MTF＞0.3(LP/MM) | 0.01 |
| Model | K682-145-0.7F29 |
| Object distance | 145 |
| Gain | 0.7x |
| Depth of field | 2.9 |
| Camera interface | C interface |
| Telecentric degree | ＜0.1 |
| Optical distortion | ＜0.1 |
| F.NO | Adjustable |
| MTF＞0.3(LP/MM) | 0.005 |
