K620~K626 Series
SiRON
9031809090
Selection
 | K620 series |
| Designed specifically for 4K line-scan cameras V interface | |
  | K621 series |
| Designed specifically for 4K7μ wire scanning cameras M42×P1 interface | |
 | K622 series |
| Designed specifically for 8K7μ line scanning cameras V interface | |
 | K623 series |
| Designed specifically for 12K5μ line scanning cameras V interface | |
 | K624 series |
| Designed specifically for 12K5μ line scanning cameras V interface | |
 | K625 series |
| Designed specifically for 16K5μ line scanning cameras V interface | |
 | K626 series |
| Designed specifically for 16K5μ line scanning cameras V interface |
Specification parameters
| Model | K620-20-0.0358A |
| Object distance | 20 |
| F.NO | 4.5-C |
| Standard magnification | 0.0358X |
| TV Distortion | 0.2％ |
| Lens mount | M42×P1 |
| Filter Size | M43×P0.75 |
| Size | φ52×48.8 |
| Weight | 234.2 |
| Model | K621-20-0.038A |
| Object distance | 20 |
| F.NO | 3.5-16 |
| Standard magnification | 0.038X |
| TV Distortion | 0.5％ |
| Lens mount | M42×P1 |
| Filter Size | M67×P0.75 |
| Size | φ70×103.8 |
| Model | K622-40-0.05A |
| Object distance | 40 |
| F.NO | 4.0-22 |
| Standard magnification | 0.05X |
| TV Distortion | ＜0.2％ |
| Lens mount | M72×P0.75 |
| Filter Size | M72×P0.75 |
| Size | φ62×71.5 |
| Weight | 983.3 |
| Model | K623-116-0.2V |
| Object distance | 116 |
| F.NO | 4.5-22 |
| Standard magnification | 0.2X |
| TV Distortion | ＜0.01％ |
| Lens mount | V-Mount(φ56) |
| Filter Size | M52×P0.75 |
| Size | φ63 |
| Weight | 478.8 |
| Model | K624-95-0.05A |
| Object distance | 95 |
| F.NO | 4.0-16 |
| Standard magnification | 0.05X |
| TV Distortion | 0.005％ |
| Lens mount | V-Mount(φ56) |
| Filter Size | M58×P0.75 |
| Size | φ55.7 |
| Weight | 456.7 |
| Model | K625-116-0.26B |
| Object distance | 116 |
| F.NO | 3.8-16 |
| Standard magnification | 0.26X |
| TV Distortion | 0.001％ |
| Lens mount | V-Mount(φ49) |
| Filter Size | M50×P0.5 |
| Size | φ61.1 |
| Weight | 395.4 |
| Model | K626-116-1B |
| Object distance | 116 |
| F.NO | 3.8-16 |
| Standard magnification | 1X |
| TV Distortion | 0.0005％ |
| Lens mount | V-Mount(φ49) |
