K630～K633 Series
SiRON
9031809090
Selection
 | K630 series |
120/150 million pixel lens F/M72×P0.75 interface | |
  | K631 series |
| 29 million -65 million pixels F/M58×P0.75 interface | |
 | K632 series |
29 million -65 million pixel C interface | |
 | K633 series |
| 29-megapixel lens F interface |
Specification parameters
| Model | K630-50-0.1F |
| Object distance | 50 |
| F.NO | 3.3-22 |
| Standard magnification | 0.1X |
| TV Distortion | ＜0.02％ |
| Lens mount | F |
| Filter Size | M58×P0.75 |
| Size | φ74×(109.3-132.3) |
| Model | K631-90-0.1F |
| Object distance | 90 |
| F.NO | 4.6-16 |
| Standard magnification | 0.1X |
| TV Distortion | 0.01％ |
| Lens mount | F |
| Filter Size | M67×P0.75 |
| Size | φ72×91.05 |
| Model | K632-90A-N |
| Object distance | 90 |
| F.NO | 4.8-22 |
| TV Distortion | ＜0.1％ |
| Lens mount | M72×P0.75 |
| Filter Size | M62×P0.75 |
| Controller | Built-in controller |
| Model | K633-35-0.1F |
| Object distance | 35 |
| F.NO | 2.8-16 |
| Standard magnification | 0.1X |
| TV Distortion | ＜0.4％ |
| Lens mount | F |
| Filter Size | M58×P0.75 |
| Size | φ61×81.5 |
| Weight | - |
