SiRON K010-3 Series Universal Laser Sensor Diffuse Reflection IP67

Name: SiRON K010-3 Series Universal Laser Sensor Diffuse Reflection IP67
Brand: SiRON
Rating: 5.0 (18 reviews)

Features:

* Not interfered by objects and background colors, stable detection Laser light source, suitable for long-distance detection of small objects.
* Built-in multi-turn potentiometer for fine adjustment of sensitivity.

Quantity:
Availability:





Inquire Add to Basket

Model:
K010-3 Series
Brand:
SiRON
Code:
9033000090

Laser Sensor Laser 650nm IP67 Long distance type Diffuse Reflection

Product Description

About selection

Selection example: K010-3 indicates the K010 series, serial numbers 3, with NPN output.

K010-3P indicates K010 series, serial numbers 3, with PNP output.

Specifications

Name	Laser sensor (universal)
Model	K010-3		K010-3P
Output state	NPN		PNP
Appearance
Type	long-distance type	Laser dass		Class1
Detection mode	Diffuse reflection (background suppression type)	Operating voltage		10～30VDC±10%
Setdistance	50～300mm	Consumption cuIrent		≤30mA
Detection distance	10~300mm	Ambient temperature		- 10℃~+50℃,No freeze
Spot size	φ1.5mm/300mm	Ambient humidity		3 5 % ～ 8 5 % R H , No Coagulation
Switching mode	Lon(light-entering action)/Don(light-blocking action) can be switched	Impact resistance		50G(500m/s²)
ndicator light	Output indicator light: Orange, laser indicator light: green	Protection class		IP67
Response time	0.3ms	Material		Shell: Contains fiberglass ABS, Lens： PMMA
Sensitivity regulation	4-turn potentiometer	ACCessories		Bracket, Screw
Light source	Laser 6 5 0 n m	Cable length		2M
