SiRON G170 Series Needle Bare Terminal/insulated

Features
  • Material: copper plated,silver plated.
  • Purified or tin plated ,improve wear resistance, finish, conductivity, and corrosion resistance.
  • Can be crimped or welded to wire and cable, widely used in new power electric vehicles, chargingpiles,electrical engineering,electrical equipment, etc.

Availability:
Quantity:
Inquire Add to Basket

PDF Export
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

  • G170

  • SiRON

  • 8538900000

G170 Series Needle bare terminal Needle insulated Terminal Copper Terminal
Product Description

About selection

Name Package Quantity Packing size
Needle bare terminal/insulated bag 1 0 0 pcs H69×Φ42


Dimension Table

Model WIRE RANGE Dimensions(mm) MAX.CURRENT
AWG  mm² ΦA ΦB C D E H A
G170 22-16
(0.25-1.65)		 1.7 3.4 4.5 14.5 2 1.7 19
G171 16.3
G172 16-14
(1.04-2.63)		 2.3 4.0 4.8 13.8 2 2.3 27
G173 21.8
Model WIRE RANGE
mm²/A.W.G		 Dimensions (mm) Color A
MAX.Current
ΦA B ΦC D
G170-V 22-16
(0.25-1.65)		 2 17.7 4 10.7
RED		 19
G171-V 19.7
G172-V 16-14
(1.04-2.63)		 2 17.7 4.5 10.7

 Bule		 27
G173-V 19.7
