SiRON T380-14 2 Optical 16 Power Unmanaged Gigabit Industrial Switch

Name: SiRON T380-14 2 Optical 16 Power Unmanaged Gigabit Industrial Switch
Brand: SiRON
Rating: 5.0 (74 reviews)

Features
● 16 10/100/1000Mbps down electrical ports to 2 1000Mbps SFP up optical ports.
● 10/100/1000Mbps rate adaptive, MDI/MDI-X adaptive, full/half duplex adaptive.
● Support wide temperature design -40℃~85℃ to meet harsh environment application requirements.
● EMC industrial level 4 electromagnetic anti-interference.
● Support dual power supply redundancy backup, built-in overcurrent 4.0A protection, connected to reverse protection input power supply.
● Support IP40 protection class, fanless design, aluminum alloy metal housing, DIN rail mounting/wall mounting.

Quantity:
Availability:





Inquire Add to Basket

Model:
T380-14
Brand:
SiRON
Code:
8428909090

unmanaged industrial switch gigabit industrial switch IP40 industrial switch 2 Optical 16 Power industrial switch

Product Description

Application industry

Industrial control application

Application in the intelligent coal mine industry

Selection reference

Model	T380-14
Electrical interface	16
Optical port	2
Speed	Gigabit
Power source	DC12-52V
Port description	16x10/100/1000Mbps RJ45 port,2x1000Mbps SFP optical port

Specification

Rj45 port		10/100/1000BaseT (X)automatic detection;Full/half-duplex MDI/MDI-X adaptive
Network protocol		IEEE802.3-CSMA/CD;IEEE802.3i-10Base-T; IEEE802.3u-100Base-TX/FX;IEEE802.3x-flow control; IEEE802.3z-1000Base-X;IEEE802.3ab-1000Base-T;
Access terminal		Phoenix Terminal
Mean time between failures		300,000 hours	Mechanical characteristic	Shell	IP40 protection grade,metal
Switch properties	Backplane bandwidth	36Gbps		Install	DIN card rail type,wall-mounted installation
	Application level	Two layers		Heat dissipation mode	Natural cooling,fanless
	Packet forwarding rate of the system	26.784Mpps	Working environment	Operating temperature	-40~85℃(-40~185°F)
	MAC table	16K		Storage temperature	-40~85℃(-40~185°F)
	Packet buffer	2M		Relative humidity	5%~95%(without condensation)
	Delay time	<3μs	LED index	Power indicator light	P1-P2(green)
	Switching mode	Storage -Forwarding		Data light	1-16 Link/Act(green)
	Overall power consumption	<10W		Optical port indicator	17-18(green)

Industry standard

EMI:
FCC Part 15 Subpart B Class A,EN 55022 Class A
EMS:
EC(EN)61000-4-2(ESD):±8kV(contact),±15kV(air)
EC(EN)61000-4-3(RS):10V/m(80～1000MHz)
EC(EN)61000-4-4(EFT):Power Port:±4kV;Data Port:±2kV
EC(EN)61000-4-5(Surge):Power Port:±2kV/DM,±4kV/CM;Data Port:±2kV
EC61000-4-6(CS):10V(150kHz~80MHz)/IEC(EN)61000-4-16(CM EMI):30V cont.300V,1s
EC 60068-2-27(Shock)/IEC 60068-2-32(Freefall)/IEC 60068-2-6(Vibration)

Dimensions
