SiRON T060~T068 Series MIL Plug Relay Terminal Block

Name: SiRON T060~T068 Series MIL Plug Relay Terminal Block
Brand: SiRON
Rating: 5.0 (28 reviews)

Features

T060 utilizes a 20pin MIL plug as the incoming line, which leads to 2 sets of 8 bit 10 pin MIL plug.
T063 utilizes a 40pin MIL plug as the incoming line, which leads to 4 sets of 8 bit 10 pin MIL plug.
T068 utilizes a 40pin MIL plug as the incoming line, which leads to 2 sets of 16 bit 20 pin MIL plug.
When used in combination with the X210 cable and other T series, it's compatible with all PLC modules with 16 bit I/O on the market, flexible wiring to maximize efficiency.

Quantity:
Availability:





Inquire Add to Basket PDF Export

Product Description

Suitable wire

主图11端子台

Type selection reference

Suitable cable

Suitable cable:T060:X215-6 X215-5 X215-1 X215-2 X213-1 X213-2 X21B-1 X21B-2 X218-2 X218-3 X218-4 X218-6 X219-3

T063 and T068: X211-1 X211-2 X215-3 X215-4 X216-3 X217-1 X217-2 X218-7 X218-8 X215-7 X215-8 X212-1 X219-1 X219-2

For details, please refer to the directory cable series

Type selection reference

Model	T060	T063	T068
Name	16-bit relay terminal block	32-bit relay terminal block	32-bit relay terminal block

Suitable PLC

OMRON	CJ1W-MD231 CJ⊃1;W-MD231 CJiW-MD232 CJ1W-MD233 CJ⊃1;W-MD234	CJ1W-ID231 CJ1W-ID261 CJ1W-MD261 CJ1W-ID232 CJ1W-ID262 CJ1W-MD263 CJ1W-MD563 CJ1W-OD231	CJ1W-OD261 CJ1W-MD261 CJ1W-OD232 CJ1W-OD233 CJ1W-OD262 CJ1W-OD263 CJ1W-MD263 CJ1W-MD563
MITSUBISHI	FX1NC-16MTFX1NC-16MT FX1NC-32MTFX1NC-32MT FX2NC-16MTFX2NC-16MT FX2NC-32MTFX2NC-32MT FX3UC-32MTFX3UC-32MT FX2NC-16EXFX2NC-16EYT FX2NC-16EXFX2NC-17EYT-C FX2NC-16EXL-C	QX41-S1 QX41 QX42 QX42-S1 QX71 QX72 QY41P QY42P	QY71 QH42P QX81 QY81P
AB	NX70-X32D NX70-X32D1 NX70-XY32 NX70-Y32T NX70-XY32
Yokogawa	F3WD32-3F	F3WD64-3N F3WD64-3F
Panasonic		FPG-XY64D2T/PF FP2-XY64D7T FP2-C1D FP2-XY64D2P FP2-X32D2 FP2-XY64D7P FP2-C1D FP2-XY64D2T FP2-X64D2 FP2-XY64D7T FP2-32T/P FP2-XY64D2P FP2-Y64T/P FP2-XY64D7P FP2-XY64D2T
SIEMENS		6ES7321-1BL00-0AA0 6ES7321-1ELO0-0AA0 SM322/6ES7322-1BL00-0AA0 SM323/6ES7322-1BL00-0AA0 6ES7321-1BH00-0AA0 6ES7321-1BHO2-0AA0 6ES7321-1BH01-0AB0 6ES7321-1BH50-0AA0 6ES7321-1CH20-0AA0 6ES7322-1FL00-0AA0 6ES7322-1BH00-0AA0 6ES7322-1BH10-0AA0 6ES7322-1FH10-0AA0 6ES7322-1BH01-0AA0
