SiRON T080 8/10 Bit Input MIL Connector Terminal Block

Name: SiRON T080 8/10 Bit Input MIL Connector Terminal Block
Brand: SiRON
Rating: 5.0 (1 reviews)

Features
● This series of wiring board is terminal input type socket board, corresponding to various terminal input signals connected to use; Equipped with 8 groups of 3P signal input ports, can access 2-wire system or 3-wire system signal; Adopt action LED display, action state is clear at a glance.
● T080/T080-P use 10pin terminal block and controller connection, convenient for remote control; When used in combination with other B series products, it can increase the efficiency of wiring work and saves time.
● T081/T081-P use 10pin terminal block and controller connection,convenient for remote control
● T085 use 10pin terminal block and controller connection,convenient for remote control.
● T080T/T081-T/T834 are shrapnel terminals for wiring, which is convenient and quick.
● The +24V input terminal of the T081-T product is equipped with a 1A resettable fuse. When the load is short-circuited or the current exceeds 1A, the fuse will automatically disconnect and automatically resume connection within 1 minute after the fault is eliminated.

Note
● Before ordering，please confirm the PLC pin definition,choose the suitable terminal.
● When PLC connection,Please be sure to use the corresponding special cable developed by our company.

Quantity:
Availability:





Inquire Add to Basket

Model:
T080
Brand:
SiRON
Code:
8536901100

T080 Terminal Block 8 bit Terminal Block manufacturer DC24V T080 Terminal Block Waterproof T080 Terminal Block

Product Description

Suitable wire

1.5mm² Following/AWG16; Stripping Length:6mm

Type selection reference

Model	T080/T080-P/T080-T	T081/T081-P/T081-T	T085	T834
Name	8-bit input terminal block	8-bit input terminal block	10-bit input terminal block	ck 4-bit input terminal block
