SiRON M272-14 Series 1.8° 14mm Two-phase Stepper Motor

Name: SiRON M272-14 Series 1.8° 14mm Two-phase Stepper Motor
Brand: SiRON
Rating: 5.0 (29 reviews)

Features

* 1.8°step angle, two-phase high-torque stepper motor;
* High precision, high efficiency and high reliability;
* Precise position control;
* It can realize precise control and convenient adjustment;
* Widely used in various motion control fields

Quantity:
Availability:





Inquire Add to Basket PDF Export

Model:
M272-14
Brand:
SiRON
Code:
8501109990

1.8° step angle 14mm frame size 0.0063N.m holding torque

Product Description

About selection

Selection example: M272-14-0630 represents the M272 series two-phase stepping motor, with a frame size of 14mm, a holding torque of 0.0063N.m, and a single axis.

Specification

Model	M272-14-0630
Radial Play	0.02mm@450g	Step Angle	1.8°
Axial Play	0.08mm@450g	Step Angle Accuracy	±5%(The entire step is unloaded)
Max.radial force	3.9N(20mm away from the flange）	Insulation Resistance	100MΩ,500VDC
Max.axial force	1.0N	Ambient Temperature	-20℃~+50℃
Dielectric Strength	300VAC/1s	Insulation Class	Class B

Electrical properties

Model	M272-14-0630
Adapter drive	M280-430
Curent perphase	0.3
Hokding torque	0.0063
Positioning torque	0.0007
Each resistance	21
Each inductance	4.2
Number of lead wires	4
Moment ofinertia	5.8
weight	0.03
Body length	30
