SiRON T380-13 8-port Unmanaged Gigabit Industrial Switch

Name: SiRON T380-13 8-port Unmanaged Gigabit Industrial Switch
Brand: SiRON
Rating: 5.0 (1 reviews)

Features
● Provides 8 10/100/1000Mbps down connection ports, can expand IEEE802.3af(15.4W)/at(30W).
● Support wide temperature design -40℃ ~ 85℃ to meet harsh environment application requirements, EMC industrial level 4 electromagnetic anti-interference.
● Support dual power supply redundancy backup, built-in overcurrent 4.0A protection, connected to reverse protection input power supply.
● Support IP40 protection class, fanless design, aluminum alloy metal housing, DIN rail mounting/wall mounting.

Quantity:
Availability:





Inquire Add to Basket

Model:
T380-13
Brand:
SiRON
Code:
8428909090

8-port Industrial Switch unmanaged industrial switch gigabit industrial switch IP40 industrial switch

Product Description

Selection reference

Model	T380-13	T380-13E
Electrical interface	8
Speed	Gigabit
Power source	DC12-52V	DC48-52V
Port description	8x10/100/1000Mbps RJ45 port	8x10/100/1000Mbps RJ45 POE port

Specification

Rj45port		10/100/1000BaseT (X)automatic detection;Full/half-duplex MDI/MDI-X adaptive
Network protocol		IEEE 802.3-CSMA/CD IEEE 802.31-10base-T IEEE 802.3U-100BASE-TX/FX IEEE 802.3X-Flow Control IEEE 802.3Z-1000BASE-X IEEE 802.3AB-1000base-T
PoE (optional)		PoE standard:Meets IEEE802.3af/IEEE802.3at; Maximum single port:15.4W(IEEE 802.3af)Maximum single port :30W(IEEE 8 PoE compatibility :IEEE 802.3af/at/Adaptive;PoE port output voltage:DC 48-57V; PoE power supply core:1/2+,3/6-

Access terminal		Phoenix Terminal
Mean time between failures		300,000 hours
Switch properties	Backplane bandwidth	16Gbps	Mechanical characteristic	Shell	P40 protection grade,metal casing
	Application level	Two layers		Install	DIN card rail type,wall-mounted installation
	Packet forwarding rate of the system	11.904Mpps		Heat dissipation mode	Natural cooling,fanless
	MAC table	8K	Working environment	Operating temperature	-40~85°℃(-40~185°F)
	Packet buffer	1K		Storage temperature	-40~85°℃(-40~185°F)
	Delay time	<3μs		Relative humidity	5%~95%(without condensation)
	Switching mode	Storage -Forwarding	LED index	Power indicator light	PWR
	Overall power consumption	<3W(Non-POE)		Interface indicator	Electrical interface(Link/ACT)

Industry standard

EMI:
FCC Part 15 Subpart B Class A,EN 55022 Class A
EMS:
EC(EN)61000-4-2(ESD):±8kV(contact),±15kV(air)
EC(EN)61000-4-3(RS):10V/m(80～1000MHz)
EC(EN)61000-4-4(EFT):Power Port:±4kV;Data Port:±2kV
EC(EN)61000-4-5(Surge):Power Port:±2kV/DM,±4kV/CM;Data Port:±2kV
EC61000-4-6(CS):10V(150kHz~80MHz)/IEC(EN)61000-4-16(CM EMI):30V cont.300V,1s
EC 60068-2-27(Shock)/IEC 60068-2-32(Freefall)/IEC 60068-2-6(Vibration)

Dimensions
