SiRON K509-6 Uhf RFID industrial reader

Name: SiRON K509-6 Uhf RFID industrial reader
Brand: SiRON
Rating: 5.0 (37 reviews)

Features:

* Industrial design, durable, in line with harsh industrial production line environment;
* Full support for EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C standard electronic tags;
* LED flashing prompts working status, buzzer ringing mode, convenient for users to control the working status of the product;
* Suitable for production lines, automated food processing production lines, automated sorting systems, parts assembly
production lines, engineering forklifts or mine engineering trucksAutomobile management and other industrial fields;
* Communication ports with isolation protection, lightning and ESD protection for key communication ports. Upgrade modes:
① serial port upgrade, ② network port upgrade;

Quantity:
Availability:





Inquire Add to Basket PDF Export

Model:
K509-6 Series
Brand:
SiRON

Industrial Reader Sturdy And Durable Waterproof and dustproof resistant to drops and shocks Uhf RFID

Product Description

Specifications

Model	K509-6
Rfchip	South Korea PR9200 dedicated RF chip
Air mouth agreement	EPCglobal UHF Class 1 Gen 2/ISO 18000-6C
Operating frequency	9 0 2 ~ 9 2 8 M H z or 8 6 5 ~ 8 6 8 M H z
Rfoutput power	13~27dBm±1dBm
Receiving sensitivity	<-70dBm
Inventory label peak speed	>50 times/second
Read distance	300~2000mm(depends on the tag)
Wnte distance	0~1000mm (related to reader parameter configuration, antenna gain, and tag type)
Tag RSSi	Supported
Supportarea	United States, Canada and other regions complying with US FCC Part 15, Europe and other regions complying with ETSI EN 302308, China, India, Japan, South Korea, Malaysia, Taiwan
Antenna	Dual-feed ceramic antenna or PCB near-field antenna
Communication interface	RJ45、RS232、RS485
Communication protocol	ModbusTCP、Modbus R TU、TCP/UDP protocols
Communication mode	10/100 Mbps Ethernet communication, WiFi (optional), supports RS232/RS485 serial communication；
WiFi (optional)	Supports IEEE 802.11 n/b/g
Heating device (optional)	Low-temperature automatic heating (at -5°C) - optional (determined according to the on-site project environment)
Communication rate	Serial port communication rate: 9600~115200 bps; RJ45 communication rate: 10/100 Mbps
Readkdisk mode	Supports continuous (automatic), command, and trigger operation modes
Data reporting mode	Buffer, timing, and real-time modes
Working condition	LED indicator light, buzzer
Rellable fimware upgrades	Expandable upgrade mechanism
Universal Input/Output (GPIO)	2-channel input, 2-channel output
Application software interface	Provides API development kit and C & Java application examples
Power source	Operating voltage: DC 9~24V
Power dissipation	Maximum power consumption: 3W; Maximum starting current: 1A
Communication harness	Industrial connection pigtail (one-to-five)
Humidness	5% ~ 95%,non-condensing
Class of protection	IEC Ip67
Operating temperature	-40ºC ~ +85ºC
Temperature protection	Supports temperature compensation function for extremely cold areas (optional)
Applicable label	K509-A series
