SiRON K509-4 High Frequency RFID Industrial Reader

Name: SiRON K509-4 High Frequency RFID Industrial Reader
Brand: SiRON
Rating: 5.0 (12 reviews)

* Full support for electronic tags in line with ISO 15693/14443A standard, support VUP protocol, support Rs485;
* LED flashing prompts the working status, which is convenient for users to control the working status of the product;
* Suitable for production lines, automated food processing production lines, automated sorting systems, parts assembly production lines and other industrial fields;
* Upgrade mode: serial port upgrade;

Quantity:
Availability:





Inquire Add to Basket PDF Export

Model:
K509-4 Series
Brand:
SiRON

Industrial Reader Sturdy And Durable Waterproof and dustproof resistant to drops and shocks Frequency RFID

Product Description

Specifications

Model	K509-4
NFCRFchip	ZC100
Alir mouth agreement	ISO 15693/ISO 14443A
Operating frequency	13.56MHz
Read distance	0~80mm (varies by tag type); e.g., for 030 industrial tag, the identification distance is 60mm
antenna	PCB Integrated Antenna
Communication interface	RS485
Communication protocol	VUP Protocol
Communication rate	Serial Port Communication Baud Rate: 9600～115200bp
Working condition	LED Indicator (Orange)
Reliable fimware upgrades	Extensible Upgrade Mechanism
Application software interface	API Development Kit provided, along with C, C#, and Java application examples
Power source	Operating Voltage: DC24V
Power dissipation	Maximum Power Consumption: 2W
Communication harness	M12 Female Connector Harness
Humidness	5%～95% (Non-condensing)
Classof protection	IEC IP67
Operating temperature	-40℃~+70℃
Storage temperature	Normal Temperature
ESDperformance	Air Discharge ±10KV, Contact Discharge ±8KV
Applicable label	K509 -A series
