D038 Series
SiRON
9405410000
ABOUT SELECTION
|
| ||
| Type analysis | ||
| ① | LED signal lamp series | D038 |
| ② | Non-smart/smart | Blank: Signal light (Z) : RS485 intelligent signal light |
| ③ | Number of color layers | 3：Red yellow green （RYG） 4：Red yellow green blue （RYGB） 5: Red yellow green blue white （RYGBW） |
| ④ | Working status |
Blank:Always on B:Always on with buzzer S:Flashing Q: Flashing with buzzer |
| ⑤ | Signal polarity | Blank：NPN P：PNP |
Note: 1. only PNP isselected when the workingstate of D038 series isshiny and shiny withbuzzer.
2. D038(Z)-3 lightsource color can only choose three layers;The workingstate can only be steady on.
3.No signal polarity is optional.
Specifications
| Model | D038-3 | D038-4 | D038-5 | D038(Z)-3 |
| Appearance |   |  |  |  |
| Luminescent lamp source color |
Red Yellow
|
Red Yellow
Green Blue |
Red Yellow Green Blue White |
Red Yellow
|
| Layer number of color | Three layers and three colors | Four layers and four colors | Five layers and five colors! | Three layers and three colors |
| Nominal voltage | 24V DC | |||
| Rated current | Red light 0.052A,yellow light 0.048A,green light 0.020A,blue light 0.02A,White light 0.02A; | |||
| Installation method | Bend | |||
| Working status | Always on/Always on with buzzer/Flashing/Flashing with buzzer | Always on | ||
| The material | Lamp shade opal PC+lamp shell aluminum alloy | |||
| Protection grade | IP20 | |||
| Bean Angle | 360° | |||
| Service life | 50000h | |||
| Environment temperature | -25～55℃ | |||
Signal polarity | NPN common positive electrode/PNP common negative electrode | -- | ||
| Standard wiring length | Standard 1500mm | USB length 1000mm | ||
