G013
SiRON
8538900000
Specifications
| Material | Flame-retardant hard P V C |
 Ambient temperature | Static temperature -40℃, continuous high temperature up to 70℃ |
| Crop tool | Fix the bottom slot, install the required wires into the slot and cover it |
| Flammability rating | UL94-V0 |
External dimension table
Model | High xwidth | Tooth width | Tooth pitc | h Thickness | Article/case | Model | High xwidth | Tooth width | Tooth pitch | Thickness | Article/case |
| G013-4040 | 40×40 | 6 | 4 | 1.45 | 50 | G013-6060 | 60×60 | 6 | 4 | 1.5 | 30 |
| G013-5025 | 50×25 | 1.4 | 50 | G013-6080 | 60×80 | 1.6 | 30 | ||||
| G013-5030 | 50×30 | 1.5 | 50 | G013-6535 | 65×35 | 1.8 | 40 | ||||
| G013-5035 | 50×35 | 1.5 | 50 | G013-6545 | 65×45 | 1.5 | 40 | ||||
| G013-5040 | 50×40 | 1.5 | 50 | G013-6565 | 65×65 | 1.5 | 30 | ||||
| G013-5045 | 50×45 | 1.5 | 50 | G013-8035 | 80×35 | 1.7 | 30 | ||||
| G013-5050 | 50×50 | 1.5 | 50 | G013-8040 | 80×40 | 1.8 | 30 | ||||
| G013-5055 | 50×55 | 1.55 | 50 | G013-8045 | 80×45 | 1.8 | 30 | ||||
| G013-5060 | 50×60 | 1.55 | 40 | G013-8050 | 80×50 | 1.8 | 30 | ||||
| G013-5080 | 50×80 | 1.7 | 30 | G013-8060 | 80×60 | 1.8 | 30 | ||||
| G013-50100 | 50×100 | 1.7 | 30 | G013-8080 | 80×80 | 1.8 | 18 | ||||
| G013-6025 | 60×25 | 1.5 | 50 | G013-80100 | 80×100 | 1.9 | 18 | ||||
| G013-6035 | 60×35 | 1.6 | 50 | G013-10040 | 100×40 | 1.7 | 30 | ||||
| G013-6040 | 60×40 | 1.5 | 50 | G013-10050 | 100×50 | 1.75 | 30 | ||||
| G013-6045 | 60×45 | 1.6 | 50 | G013-10080 | 100×80 | 1.9 | 18 | ||||
| G013-6050 | 60×50 | 1.5 | 40 | G013-100100 | 100×100 | 2 | 18 |
