K053-1 Series
SiRON
8479909090
About selection
Selection example:
K053-1-1 indicates the K053 series, 1 wide-range displacement sensor, 1 serial number, NPN.
K053-1-1A indicates the K053 series, 1 wide-range displacement sensor, 1 serial number, NPN + analog quantity.
Specifications
Name | Wide range displacement sensor | ||
Model | K053-1-1 | K053-1-1A | K053-1-1R |
Output mode | NPN | N P N + Analog quantity | NPN+RS485 |
Appearance |   | ||
Types of | Diffuse reflection | ||
Distance of re ference | 235mm | ||
Distance of detection | 35～435mm | ||
Ful-scale | 400mm | ||
Repeatability | 35-135mm:0.1mm;135-235mm:0.3mm;235-335mm:0.8mm;335-435mm:1.5mm | ||
Precision of linearity | 35-200mm:±0.1%F.S.;200-400mm:±0.2%F.S.;400-435mm:±0.3%F.S. | ||
Operating voltage | DC 12~24V±10% | ||
Consume (no-load)current | <30mA(when the supply voltage is 24V DC),<60mA(when the supply voltage is 12V DC) | ||
Response time | 1 . 5ms/5ms/10ms,switchable | ||
Lightsource(medium,wavelength) | Red diode laser, wavelength 655nm | ||
Output power | <1mW | ||
Class of laser | IEC Class 2 | ||
Temperature drift characteristic | ±0.03%F.S./°℃ | ||
Control output | The collector of NP is open, ≤50mA/DC 24V, and the residual voltage is < 1.5V | ||
Analog output voltage | Output range: 0-5V(5.2V upon alarm) | ||
Analog output curent | Output range: 4~20mA(0mA upon alarm), switchable | ||
Output action | Light.on(light-entering action)/Dark.on(light-blocking action) can be selected | ||
| Class of protection | IP67(IEC) | ||
| Ambient temperature | Operating hours: -10°C to 45°C; Storage time :-20°C to 60°C, no freezing | ||
| Ambient humidity | When in operation: 35% to 85% RH Storage :35% to 85% RH, no condensation | ||
| Protection circuit | Reverse polarity protection/surge protection/short circuit protection | ||
| Vibration resistance | 10 to 55Hz, dual amplitude 1.0mm, 30 minutes in each of the X/Y/Z directions | ||
| Impact resistance | 300m/S⊃2;, three times each in the X, Y and Z directions | ||
| Material | Shell: Aluminum alloy; Lens: PMMA; Wire: PVC(polyvinyl chloride) | ||
| Connection mode | 2-meter 5-core standard wire (wire diameter 4.0mm), customizable length | ||
| Line length | 2-meter 5-core standard wire | ||
| Weight | About 85g | ||
| Pilot lamp | Output indicator light: yellow; Power indicator light: Green | ||
