H450
SiRON
8538900000
Order
| Model | Cable Length |
| H450-4 | Standard : 3000mm |
※ Other lengths include :5000mm, 10000mm with mating plugs;
The line length is 3000/100, L1=3000. L2=100(wiring diagram)
※ F* The above are standard cable models. If you need to use high-flexibility cables, please add "T" after the model. For more details, please consult the relevant salesperson.
Type selection reference
| Model | H450-4 | H450-6 | H450-8 | H450-4/6/8F | H450-4/6/8WF |
| Name | MiniType 4-bit junction box | MiniType 6-bit junction box | MiniType 8-bit junction box | MiniType4/6/8-bit junction box | |
Specifications
| Input | Nominal operating current | 1A |
| Nominal coil voltage | DC24V | |
| Operating temperature | 90℃~100℃ | |
| Shell | A B S + P C material | |
Associated product
X840-6-P/X840-6-S2 X840-8-P/X840-8-S2 X840-10-P/X840-10-S2
