SiRON H402-B Series 45 /60 Lightweight Cantilever Assembly

Name: SiRON H402-B Series 45 /60 Lightweight Cantilever Assembly
Brand: SiRON
Rating: 5.0 (27 reviews)

Features

This series of miniature cantilever components are matched with 40x50mm aluminum tubes;
For hanging or supporting small control box (7 inches);
The surface of the aluminum tube and components is treated with plastic spraying;
All components are made of aluminum alloy die-casting process.

Quantity:
Availability:





Inquire Add to Basket PDF Export

Product Description

Order

Model	Serial number
H402-B	1

Note: Applicable to control boxes with a depth of 80 - 210 mm.

Type selection reference

Small base	Product name	*(kg) Weight(kg)	Honizontal rotation angle	Material
H402-B-1	box seat	0.9	0~320°	Pack alloy
H402-B-2	box seat	0.9	0~320°	Pack alloy
H402-B-3	10°box seat	0.9	0~320°	Pack alloy
H402-B-4	Right-angle box seat	1.1	0~320°	Pack alloy
H402-B-5	Right-angle box seat	1.1	0~320°	Pack alloy
H402-B-6	Right-angle10°box seat	1.1	0~320°	Pack alloy
H402-B-7	Intersection angle	1.06	/	Pack alloy
H402-B-8	top seat	1.1	0~320°	Pack alloy
H402-B-9	top seat	1.1	0~320°	Pack alloy
H402-B-10	Raise the top seat	1.3	0~320°	Pack alloy
H402-B-11	Horizontal wall base	1.3	0~320°	Pack alloy
H402-B-12	Lengthen the horizontal wall base	1.5	0~320°	Pack alloy
H402-B-13	Mid-joint	1.4	0~320°	Pack alloy
H402-B-14	Vertical wall base	1.2	0~320°	Pack alloy
H402-B-15	Extend the vertical wall base	1.5	0~320°	Pack alloy
H402-B-16	Base	0.6	/	Pack alloy
H402-B-17	Small base	0.3	/	Pack alloy
H402-B-18	Slanting Base	0.6	/	Pack alloy
H402-B-19	revolving base	0.9	0~320°	Pack alloy
H402-B-20	revolving base	0.9	0~320°	Pack alloy
H402-B-21	Rotational angle	1.3	0~320°	Pack alloy
H402-B-22	Rotate the base of the box	1	0~320°	Pack alloy
H402-B-23	10°Rotate the base of the box	1.1	0~320°	Pack alloy
H402-B-24	15°bevel	0.35	/	Pack alloy
H402-B-25	Vertical box base	1.5	0~320°	Pack alloy
H402-B-26	Extend the vertical box seat	1.7	0~320°	Pack alloy
H402-B-27	Wall-mounted box base	1.5	0~320°	Pack alloy
H402-B-28	Box reinforcing plate	0.5	/	Pack alloy
